    Rolled Sugar Cone Production Line

    Ask Lasest Price
    Brand Name : OEM
    Model Number :
    Certification : ISO
    Price : Negotiation
    Payment Terms : T/T, L/C, T/T, Western Union
    Supply Ability : Sufficient Supply
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    Rolled Sugar Cone Production Line

    Rolled Sugar Cone Production Line


    Features


    1. Rolled Sugar Cone Production Line is driven by the 3 phases power and backing oven is heating with gas (natural gas or liquid gas), electric ignition, oven temperature electronic display. The producing ability is very high and it is all automatic from spraying the batter, baking, forming, falling off from molds, conveying products, stacking and counting.

    2. Rolled Sugar Cone Production Line is suitable for making flat mouth sugar cone length less than 120mm. Cone degree, weight, thickness and pattern spacing customized according to customer demand.


    3. Rolled Sugar Cone Production Line is consist of 280*240mm baking plates, plates material is high-qualified ductile cast iron, each plates can make two cone sheets.


    Introduction


    1. We produce many kinds of Automatic Rolled Sugar Cone Machine , such as semi-automatic cone machine,automatic cone machines and ice cream cone production line.

    2. The machine is driven by the 3phase power and baking oven is heating with gas(natural gas or liquid gas).The producing ability is very high and it is all automatic from spraying the batter, baking, forming,falling off from molds, conveying products, stacking and counting.


    ModelGG37×2-16AGG45×2-16AGG53×2-16A
    Drive motor380V 1.5KW380V 1.5KW380V 2.2KW
    Rolling system motor380V 0.37KW380V 0.37KW380V 0.37KW
    Air blower380V 1.1KW380V 1.1KW380V 1.6KW
    Gas consumption(kg/h)5-76-78-12
    Producing capacity(pcs/h)3500-40004500-50005500-6000
    Food-grade conveyor5000*460*5005000*460*5005000*460*500
    Automatic counter3000*460*4003000*460*4003000*460*400
    Mixer190L190L190L
    Machine measurement (m)7.05×1.90×1.738.52×1.90×1.739.80×1.90×1.73
    Total weight4200kgs4800kgs5300kgs
